This new A4 colour MFP is designed specifically for medium and large-sized work groups, offering both reliability and fast output speeds in both colour and b/w and now complying with the newest environmental standards. The convenient touch panels provide simple, direct access to the multifunctionals’ numerous functions. What’s more, dedicated program keys and KYOCERA’s open solution platform HyPAS can help further optimize your document workflow. And for your bottom line it offers you an attractive TCO.
Model
PF-5100
Type
Paper Feeder
Capacity (sheets)
500 sheets
Dimensions (W x D x H)
148 x 210 mm–216 x 356 mm
Paper size
60–220 g/m2; A4, A5, A6, B5, Letter, Legal, Custom
Model
MS-5100
Type
Convenient Stapler
Capacity (sheets)
20 sheets
Dimensions (W x D x H)
1,500 staples includes
Paper size
Semi automatic stapler: on the front side, one corner stapling
Model
SH-13
Type
Stapler cartridge
Dimensions (W x D x H)
2 x 1,500 staples included
Paper size
for MS-5100
TK-5275K
Average continuous black toner yield 8,000 pages in accordance with ISO /IEC 19798. Average continuous black toner yield 3,500 pages in accordance with ISO /IEC 19798 (starter toner)
TK-5275C
Average continuous cyan toner yield 6,000 pages in accordance with ISO /IEC 19798. Average continuous cyan toner yield 2,500 pages in accordance with ISO /IEC 19798 (starter toner)
TK-5275M
Average continuous magenta toner yield 6,000 pages in accordance with ISO /IEC 19798. Average continuous magenta toner yield 2,500 pages in accordance with ISO /IEC 19798 (starter toner)
TK-5275Y
Average continuous yellow toner yield 6,000 pages in accordance with ISO /IEC 19798. Average continuous yellow toner yield 2,500 pages in accordance with ISO /IEC 19798 (starter toner)
MMDR3-1024
1,024 MB RAM Expansion
MDDR3-2GB
2,048 MB RAM Expansion
HD-6
32 GB SSD hard disc for easy document management
HD-7
128 GB SSD hard disc for easy document management
Data Security Kit (E) AC
In line with ISO 15408 (Common Criteria) with security level EAL3. Only 4in1 MFP-models carry official CC-Certification
IB-36
Wireless LAN (802.11b/g/n) with Wi-Fi Direct
IB-50
Gigabit-Ethernet board 10BaseT/100BaseTX/ 1000BaseT
USB IC Card Reader + Card Authentication Kit (B)
Support for various authentication keys available
Scan extension Kit (A) AC
Scan to searchable PDF (embedded OCR) or to MS Office (docx, xlsx, pptx), HD-6, HD-7 or SD-card is needed
Card Reader Holder 10
To integrate the USB IC Card Reader
UG-33
ThinPrint support
PCL Barcode SD
Adds additional one- and two-dimensional barcodes to the KYOCERA device (as well as the resident and machine-readable fonts OCR-A, OCR-B)
Card Authentication Kit (B)
Support for various authentication keys available
General type
Colour Multifunctional for A4 format
Technology
KYOCERA ECOSYS, Colour Laser
Engine speed
Up to 30 pages A4 per minute in colour and b/w
Resolution
1,200 x 1,200 dpi (print),
600 x 600 dpi(scan/copy)
Warm-up time
Approx. 26 seconds or less
Time to first print
Approx. 6.5/7.5 seconds or less in b/w / colour
Time to first copy
Approx. 8.5/10 seconds or less in b/w / colour
Dimensions (W x D x H)
475 x 558 x 616 mm
Weight
Approx. 35.4 kg including toner container
Power consumption
Printing: 496W, Copying: 521W, Ready mode: 70W, Sleep mode: 0.6W
Power source
AC 220 ~ 240 V, 50/60 Hz
Noise (ISO 7779)
Noise (Sound pressure level: ISO 7779 / ISO 9296) Copy / Print in colour: 49.5 dB(A) LpA, Quiet mode in colour: 46.6 dB(A) LpA, Sleep-mode: Immeasurable low
Safety standards
TUV/GS, CE – This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard.
General memory
Standard 1024 MB, Max. 2048 MB
Input capacity
100-sheet multi-purpose tray, 60-220 g/m², A4, A5, A6, B5, Letter, Legal, Folio, Envelopes, Custom (70 x 148 to 216 x 356 mm), 250-sheet standard universal paper cassette, 60-163 g/m², A4, A5, A6, B5, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm)
Max. input capacity with options
1,850 sheets
Duplex unit
Duplex as standard supports 60-163 g/m²; A4, A5, B5, Letter. Legal
Max. output capacity
250 sheets face-down with paper full sensor
Document processor
Reversing: 75-sheet, 50-120 g/m², A4, A5, A6, B5, Letter, Legal, Custom (105 x 148 mm to 216 x 356 mm)
General paper handling
All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions.
Input capacity
100-sheet multi-purpose tray, 60-220 g/m², A4, A5, A6, B5, Letter, Legal, Folio, Envelopes, Custom (70 x 148 to 216 x 356 mm), 250-sheet standard universal paper cassette, 60-163 g/m², A4, A5, A6, B5, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm)
Max. input capacity with options
1,850 sheets
Duplex unit
Duplex as standard supports 60-163 g/m²; A4, A5, B5, Letter. Legal
Max. output capacity
250 sheets face-down with paper full sensor
Document processor
Reversing: 75-sheet, 50-120 g/m², A4, A5, A6, B5, Letter, Legal, Custom (105 x 148 mm to 216 x 356 mm)
General paper handling
All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions.
Max. original size
A4/Legal
Digital copy features
Auto Colour Mode, Scan-once-copy-many, electronic sort, 2in1, 4in1, ID-card copy, job reserve, priority print, program, auto duplex copy, continuous scan, auto cassette change, copy density control, skip blank page
Exposure modes
Auto, manual: 9 steps
Preset magnification ratios
7 Reductions/5 Enlargements
Zoom range
25 – 400 % in 1% steps
Continuous copy
1 – 999
Image adjustments
Text + Photo, Photo, Text, Map, Printed document
Compression format
MMR/JPEG
File type
TIFF, PDF, PDF/A, JPG, XPS, Open XPS,Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u, MS Office file and Searchable PDF (optional Scan Extension Kit(A) is required)
Scan features
Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Skip blank page
Original recognition
Text, photo, text + photo, light text, optimized for OCR
Max. scan size
A4 / legal
Scan functionalities
Scan-to-Email, Scan-to-FTP , Scan-to-SMB, Scan to USB Host, Network TWAIN, WIA, WSD scan
Scan resolution
600, 400, 300, 200 dpi (256 grey scales per colour)
Scan speed
60 ipm (300 dpi, A4, b/w), 40 ipm (300 dpi,A4 colour), 26 ipm (300 dpi, A4, b/w) (Duplex), 17 ipm (300 dpi, A4 colour) (Duplex)
Compatibility
ITU-T Super G3
Modem speed
Max. 33.6 kbps
Scanning speed
2 seconds or less
Transmission speed
3 seconds or less
Scanning density
Normal: 200 x 100 dpi, Fine: 200 x 200 dpi, Superfine: 200 x 400 dpi, Ultrafine: 400 x 400 dpi, Halftone: 256 greyscales
Max. original size
A4 / legal
Compression method
JBIG, MMR, MR, MH
Fax features
Network faxing, Duplex transmission and reception, Encrypted transmission and reception, Polling transmission and reception, Broadcast
